Cibes Outdoor Home Lift Series: Weatherproof, Space-Saving Access for Tropical Homes

The Cibes Outdoor Home Lift Series delivers a weatherproof, space-saving outdoor home lift solution, purpose-built for tropical climates and modern architecture.

Designed for Southeast Asia’s humid, coastal, and high-rainfall environments, each lift features:
• Anti-corrosive components
• IP-rated controls
• Prefabricated shaft, no pit or machine room required

From narrow Bangkok townhouses to beachside villas in Bali, Cibes outdoor lifts integrate seamlessly into both new builds and retrofits.

They provide architects, developers, and homeowners with reliable vertical mobility that combines Scandinavian design, advanced safety, and long-term durability.

Weather Resistant by Design: Built for Tropical Realities

Unlike traditional elevators, Cibes outdoor lifts are engineered to perform year-round—handling humidity, rainfall, temperature fluctuations, and salt-laden coastal air.

Key Weather Protection Features:

• Anti-corrosive bottom frame & platform coating
• Flood-protected electrical compartment
• IP55-rated call buttons with sealed aluminum faceplates
• Weather-resistant shaft glass panels with rubber sealing
• Aluminum swing doors
• Canopies in steel to shield doors
• Slanted outdoor roof engineered for rain and snow loads (up to 3kN/m²)

Temperature Operating Range: −10°C to +30°C (with additional thermal options for colder or hotter zones)

This makes it a perfect outdoor lift for countries like Thailand, Vietnam, Indonesia, the Philippines, Malaysia, and even colder highland areas like Chiang Mai or Baguio.

All-Inclusive, Space-Smart Lift System

Cibes doesn’t just sell lifts, it delivers a complete, prefabricated outdoor elevator system with minimal structural

requirements. No deep pit. No machine room. No custom shaft fabrication.

Included in the modular package:

• Ready-made shaft (steel or glass)
• Platform lift with 70% space efficiency
• Structural anchoring hardware
• Roof + canopies + weather insulation features

Installation time: just 5-15 days depending on number of floors and size.
The system is designed for retrofitting older homes or minimizing construction in new projects.

Compact Yet Powerful: Platform Sizes & Configuration

Cibes Outdoor Lift Series can have the entire shaft and platform system can be installed externally along walls, in lightwells, or in semi-covered breezeways, connecting upper floors with ground access or garden spaces.

Drive System: EcoSilent™ screw-driven mechanism (40 dB operation, no oil, no belt)

Capacity: up to 400 / 500 kg depending on models

Travel Distance: Up to 6 stops / 20 meters

Architectural Impact with Minimal Disruption

With up to 73% of the total footprint dedicated to passenger space, the Cibes outdoor lift is the most space-efficient lift in its class.

It offers a design-forward way to:

• Preserve valuable indoor real estate
• Add vertical access to upper floors or rooftops
• Retrofit mobility without compromising interiors
• Maintain visual transparency with glazed panels and sleek aluminum trims

Scandinavian Engineering, Southeast Asia Resilience

Developed by the Cibes Lift Group of Sweden, established in 1947 and present in over 70 countries, the outdoor lift series is:

• EN81-41, CE, SIL-3 compliant
• Adapted to humid, tropical climates
• Supported by local teams in Thailand, Vietnam, Philippines, and more

Whether for elderly access, future-proofing your home, or enhancing architectural flow, the Cibes outdoor home lift offers a trusted, durable, and elegant solution.

Frequently Asked Questions On Outdoor Lifts

Q: What makes Cibes the ideal choice for an outdoor home lift in Southeast Asia?

A: Cibes lifts are engineered for durability in tropical climates. Our weather-resistant design, featuring a sealed, prefabricated shaft and anti-corrosive components, ensures reliable performance. The machine-room-less, screw-driven system is not only space-efficient but also allows for a swift installation in just a few days, minimizing disruption to your home.

Q: Can a Cibes lift be installed in demanding environments like beachfront properties or areas with high rainfall?

A: Absolutely. Our lifts are designed for such conditions. The shaft is fully sealed to prevent water ingress, all critical components are treated to be anti-corrosive, and the controls are IP-rated for weather protection. For added peace of mind, we also offer optional canopies.

Q: Does the installation require a deep pit or a separate machine room?

A: No, and that’s a key advantage of our design. A Cibes lift can be installed with a minimal pit of just 50-70 mm, or even with no pit at all through the use of a small, convenient ramp. This makes installation possible in a wider range of properties.

Q: How does a Cibes lift differ from a conventional elevator?

A: Cibes lifts are a modern alternative to traditional elevators. Our machine-room-less and screw-driven mechanism eliminates the need for a bulky hydraulic system, making it perfect for retrofitting into existing homes with limited space. The modular design allows for a faster, more efficient installation process.

Q: What kind of support and service can I expect in Southeast Asia?

A: We have a strong and dedicated presence across the region. Cibes has direct subsidiaries and certified partners in Thailand, Vietnam, Malaysia, the Philippines, and Indonesia, ensuring you have access to expert sales, installation, and maintenance support

Q: How much space is needed to install a Cibes outdoor lift?

A: One of the key benefits of a Cibes lift is its compact footprint. Our space-saving design dedicates up to 73% of its area to the passenger platform. Even if you have as little as one square meter of available space, we likely have a solution that will fit your home.

Q: Are Cibes lifts wheelchair accessible?

A: Yes, accessibility is a core part of our design philosophy. Many of our models are spacious enough to comfortably accommodate a wheelchair. We can provide detailed dimensions and specifications to ensure the lift meets your specific accessibility needs.

Q: What customization options are available for the outdoor lift series?

A: We understand that aesthetics are important. You can customize your Cibes lift to match your home’s exterior with a wide range of colors, materials, and finishes. From panoramic glass panels to custom lighting, we can help you create a lift that is both functional and beautiful.

Q: What are the safety features of a Cibes outdoor lift?

A: Safety is our top priority. Cibes lifts are compliant with stringent European safety standards and include features such as an emergency stop button, a battery backup for safe lowering during a power outage, and an alarm system.

Q: How energy-efficient is a Cibes lift?

A: Our EcoSilent screw-driven system is designed for energy efficiency, consuming less power than a traditional hydraulic elevator. This not only reduces your environmental impact but also contributes to lower operating costs over the life of the lift.

Compatible Models for Outdoor and Semi-Outdoor Installation

Cibes offers a versatile range of weather-resistant home lift models that can be configured for semi-outdoor or fully outdoor use, where the lift shaft is installed outside the building while the doors open into the interior. The following models are fully compatible with outdoor setups:

• Cibes V80 Series: Available in multiple design tiers (Elegance, Aurora, Galaxy), these lifts offer panoramic glass shafts, LED lighting, and up to 41 size options, ideal for tropical and humid climates.

• Cibes V90 Series: Featuring Scandinavian aesthetics and EcoSilent™ screw drive, the V90 lifts come with high-grade weather sealing and optional outdoor-ready components for external installations.

• Cibes Uno: The entry-level yet feature-rich model, Uno provides 41 sizes, standard steel shafts, and essential weatherproofing for small footprint outdoor configurations.

• Cibes Air®: Designed with minimalist elegance, Cibes Air combines form and function with 360° glass shaft options, IP-rated controls, and over 17 platform sizes, including outdoor-ready builds.

• Cibes Kithara: A premium model built for luxury homes, Kithara lifts support outdoor shaft installation with optional panoramic glass, ambient lighting, and seamless architectural integration.

All models include optional features such as anti-corrosive components, outdoor roofs, call button weather sealing, and flood-protected electrical systems, making them ideal for Southeast Asian weather conditions and design aesthetics.

A New Standard in Outdoor Home Lifts

In today’s evolving architecture, accessibility and aesthetics must go hand in hand. With the Cibes Outdoor Lift Series, your home’s exterior becomes an opportunity, not a constraint.

Whether it’s connecting a sloped driveway to an upper terrace or adding multi-level access in a coastal residence, Cibes helps you build upward, without building out.

Now is the time to bring mobility outside.

Now is the time to choose Cibes.
